/ABB 88VK01B-E GJR2312200R1010 Coupling Module

ABB 88VK01B-E GJR2312200R1010 Coupling Module

ABB Coupling Module
  • item no.:

    88VK01B-E
  • lead time:

    2-3 work days
  • product orgin:

    Switzerland
  • shipping port:

    Xiamen China
  • payment:

    T/T
  • price range:

    1-999/1$
  • color:

    Depends on the material
  • product details
  • Manufacture:ABB
  • Model:88VK01B-E
  • Ordering information:GJR2312200R1010
  • Catalog:ABB Procontrol
  • Description:ABB 88VK01B-E GJR2312200R1010 Coupling Module
  • Origin:United States (US)
  • HS Code:85389091
  • Dimension:16cm*16cm*12cm
  • Weight:0.8kg

ABB 88VK01B-E GJR2312200R1010 Motor Protection Functions


  • Overload protection (adjustable trip class)
  • Phase loss/unbalance protection
  • Locked rotor protection
  • Ground fault protection (optional)
  • Thermal overload protection with memory

ABB 88VK01B-E GJR2312200R1010 Control & Monitoring


  • Start/stop control via built-in contactor control relay
  • 4-digit LED display for current/motor load monitoring
  • Programmable alarm and trip outputs

ABB 88VK01B-E GJR2312200R1010 Technical Specifications


  • Current Range: 5-50A (adjustable)
  • Supply Voltage: 100-240V AC/DC
  • Output Relays: 2 changeover (trip & alarm)
  • Communication: Optional fieldbus modules (Profibus, Modbus)
  • Mounting: DIN rail (35mm)

ABB 88VK01B-E GJR2312200R1010 Environmental Ratings


  • Operating Temperature: -25°C to +55°C
  • Protection Class: IP20

ABB 88VK01B-E GJR2312200R1010 Typical Applications


  • Industrial motor protection (pumps, fans, conveyors)
  • HVAC systems
  • Machine tools
  • Compressor systems

ABB 88VK01B-E GJR2312200R1010 Installation Guide


  • Mounting
Install on 35mm DIN rail
Allow minimum 50mm clearance above/below for ventilation
  • Wiring
Current Inputs: Connect to motor CTs or direct sensing
Control Inputs: Start/stop signals
Output Relays: Connect to contactor/PLC
  • Configuration
Set motor FLC (Full Load Current) via front panel
Adjust trip class (10/20/30)
Program alarm thresholds

ABB 88VK01B-E GJR2312200R1010 Maintenance


  • Monthly Checks
Verify display readings match motor current
Test manual reset function
Check for abnormal heating
  • Annual Checks
Calibrate current sensing
Verify trip thresholds

ABB 88VK01B-E GJR2312200R1010 Ordering Information


  • Base Unit: 88VK01B-E
  • Accessories:


Communication module (specify protocol)

Current transformers (if not direct connect)


ABB 88VK01B-E GJR2312200R1010 Replacement Options


  • ABB 88VK02B-E (higher current range)
  • ABB ES100 series (newer equivalent)
