ABB CI867AK01 3BSE0929689R1 Modbus TCP Interface

ABB Modbus TCP Interface

item no.:
CI867AK01
lead time:
1-2 days
product orgin:
Switzerland
shipping port:
Xiamen
payment:
T/T
Condition:
NEW

contact now

product details

Manufacture：ABB
Model：CI867AK01
Ordering information：3BSE0929689R1
Catalog：ABB 800xA
Description：ABB CI867AK01 3BSE0929689R1 Modbus TCP Interface
Origin：United States (US)
HS Code：85389091
Dimension：16cm*16cm*12cm
Weight：0.8kg

ABB CI867AK01 3BSE0929689R1 Description

MODBUS TCP is an open industry standard widely spread due to its ease of use. It is a request response protocol and offers services specified by function codes.
  MODBUS TCP combines the MODBUS RTU with standard Ethernet and universal networking standard TCP. It is an application-layer messaging protocol, positioned at level 7 of the OSI model.
  The CI867A/TP867 is used for connection between an AC 800M controller and external Ethernet devices using Modbus TCP protocol.
  The CI867 expansion unit contains the CEX-Bus logic, a communication unit and a DC/DC converter that supplies appropriate voltages from the +24 V supply via the CEX-Bus.
  The Ethernet cable must be connected to the main network through an Ethernet switch.
  The CI867A module will only work with System 800xA 6.0.3.3, 6.1.1. and subsequent versions.

ABB CI867AK01 3BSE0929689R1 Features and benefits

The CI867A can be set redundant and supports hot swap.
CI867A is a single channel Ethernet unit; Ch1 supports full duplex with 100 Mbps speed.
Both master and slave functionality are supported.
A maximum of 70 slave and 8 master units per CI867A can be used.
