ABB RLM01 3BDZ000398R1 Communication Module RLM 01

PROFIBUS Redundancy Link Module RLM01

item no.:
ABB RLM01
lead time:
1-2 days
product orgin:
Switzerland
shipping port:
Xiamen
payment:
T/T
Condition:
NEW

contact now

product details

PROFIBUS Redundancy Link Module RLM01

The RLM01 module can be positioned directly next to a master, in front of a bus segment with several slaves, or in front of an individual slave. Several PROFIBUS stations with redundant couplers can be connected directly to the PROFIBUS that has been made redundant by RLM01. Stations with just one interface can be positioned either on the A line or on the B line. Each RLM01 PROFIBUS interface can operate up to 31 PROFIBUS stations.

Serial Interfaces

Connections A , B and M
Transmission rate 9.6 kBit/s to 12 MBit/s
Type RS 485
Connection 9-pin Sub-D connector
Electrical isolation VDE 0110, functionally isolating
Test voltage 500 Veff
Device protection class 3

Data telegram delay

A/B --> M:1 Bit times [us] + 0.6 us
M --> A/B 4 Bit times [us] + 0.6 us

Power Supply

Operating voltage: 24 VDC (+20 .. +33 V)
Power consumption: 150 mA typically at 24 V
Power loss: Approx. 3.6 W
Connection: 8-pin terminal strip
Wire cross section: 0.14 ... 1.5 mm2

Design

Dimensions: 134 x 56 x 70 mm (H,W,D)
Weight: 330 g
Protection: IP 20
Attachment: DIN mounting rail, 35 mm

Benefits

Three PROFIBUS ports
Transparent for PROFIBUS configuration, i.e. no slave address required
Supports transmission rates of 9.6 Kbps to 12 Mbps
Serve up to 31 Profibus clients. While using repeaters (optical - electrical), this number can extend
Errors are signalized via an LED on the frontplate and a signaling contact
Specific messages that can be read at the 8-pin terminal strip serve diagnostic purposes
CE, UL and CSA certified
Type Approval Certificate "Germanischer Lloyd" for use in marine area
