/APF195 204-195-000-021 24 VDC 0.26 A Power Supply

APF195 204-195-000-021 24 VDC 0.26 A Power Supply

Power Supply
  • item no.:

    204-195-000-021
  • lead time:

    12-18 weeks
  • product orgin:

    Switzerland
  • payment:

    T/T
  • Condition:

    NEW
  • product details

APF195 204-195-000-021 KEY FEATURES AND BENEFITS

• From the vibro-meter® product line

• Input: 9.4 to 36.0 VDC

• DIN-rail mounting

• DC input and two 24 VDC outputs

• The two 24 VDC outputs of an APF195 can be connected in parallel in order to provide an output current up to 0.26 A


APF195 204-195-000-021 APPLICATIONS

• Outputs can be connected in parallel for increased output current

• Ideal for use with machinery monitoring system


APF195 204-195-000-021 DESCRIPTION

        The APF195 is a 24 VDC 0.26 A power supply for use in industrial applications such as machinery monitoring.
        A single output of an APF195 power supply can be used to power any equipment requiring 24 VDC up to 0.13 A (3.1 W), for example, external hardware such as GSI12x galvanic separation units. Both outputs of an APF195 can be connected in parallel in order to increase performance and provide up to 0.26 A (6.2 W).
        The APF195 is DIN-rail mounting and is typically installed in a cubicle containing other equipment such as VM600Mk2/VM600 and/or VibroSmart® monitoring systems.

APF195 204-195-000-021 Physical

  • Mounting : Mounts on a TH 35 DIN rail (according to EN 50022 / IEC 60715).
  • Dimensions : 50 × 72 × 97 mm (1.97 × 2.83 × 3.82 in)

APF195 RELATED PRODUCTS

  • APF196 24 VDC 3 A power supply
  • APF197 24 VDC 5 A power supply
  • APF198 24 VDC 7.5 A power supply
  • APF200 24 VDC 3.75 A power supply with Ex certification
  • APF201 24 VDC 7.5 A power supply with Ex certification
  • APF202 24 VDC 5 A power supply with Ex certification
  • ASPS VM600Mk2/VM600 auxiliary sensor power supply


APF195 Datasheet Download
