CI186 Loop powered Accelerometer Dual Output Accelerometer

Output Accelerometer
  • item no.:

    CI186
  • lead time:

    2-3 work days
  • product orgin:

    Switzerland
  • shipping port:

    Xiamen China
  • payment:

    T/T
  • color:

    Depends on the material
  • Condition:

    New
product details
Details


Manufacture

Switzerland

Model

CI186

Conditon

New

Warranty

12 months


Ordering Information




Mounting Accesories



Technical Specifications


*Current Output : 4-20mA proportional to RMS velocity (mm/s)

*AC Output : AC voltage proportional to acceleration (g)

*Frequency Response: 2 Hz to 1 kHz ±10% , -3 dB at 0.8Hz for AC output

*Dynamic Range : 30g peak for 100mV/g: 60g peak for 50mV/g

*Mounted Resonance : 5 kHz min

*Bias Voltage (AC output) : 3 Volts

*Isolation : Base isolated

*Operating Temp Range : -25 to 90 ºC

*Temperature Sensitivity : 0.08%/ºC

*Transverse Sensitivity : Less than 5%

*Supply Voltage : 12-32 Volts DC (4-20 mA)

*Standard Cable : 5 metres armoured PTFE

*Case Material : Stainless steel

*Weight : 150 gms (nominal)

*Sealing : IP67

*Mounting Torque : 8 Nm

*Mating Connector : 3 pin 62 GB for CT connection


Download Datasheet






  CI186 Datasheet PDF Download Link
