 /CMC16 200-530-025-014 Condition Monitoring Card

product categories

New Arrivals

200-530-025-014 200-530-025-014

CMC16 200-530-025-014 Condition Monitoring Card

Condition Monitoring Card

  • item no.:

    200-530-025-014

  • lead time:

    2-3 work days

  • product orgin:

    USA

  • shipping port:

    Xiamen China

  • payment:

    T/T

  • color:

    Depends on the material
  • product details

CMC16 200-530-025-014 FEATURES


  • 16 individually configurable dynamic channels
  • 16 parallel programmable anti-aliasing filters and ADCs
  • First 4 channels also configurable as tacho inputs
  • Last 12 channels also configurable as process values
  • VME architecture
  • Configurable Synchronous and Asynchronous sampling
  • High resolution 3200-line FFT
  • 10 fully configurable processed outputs per channel, which can be either frequency bands or time-domain based outputs
  • 6 configurable alarms per processed output with hysteresis deadbands
  • Schedule, ‘on-alarm’ and ‘on exception’ based logging
  • On-board buffer storage
  • Status indication by 3-colour LED on front panel
  • Live insertion / removal of cards with automatic configuration
  • Ethernet and Serial RS-4851 communication options
CMC16 200-530-025-014 SPEED/PHASE REFERENCE INPUT

  • Triggering method : Rising or falling edge
  • Input voltage range : 1 to 24 V pulse (AC coupled in the -24 V / +24 V range)
  • Frequency range : 0.25 to 10,000 Hz
  • Maximum pulses per revolution : 128 for speed calculation (1 only for phase reference)
  • Minimum rise time : 4 volts/second
  • Minimum pulse duration : 10 μs
  • Max. common mode voltage : 50 V
  • Machine speed resolution : ±1 rev/min
  • Maximum number allowed : 4, amongst the first four channels*
CMC16 200-530-025-014 PHYSICAL

  • Height : 6 U (262 mm, 10.31 inches)
  • Width : 20 mm (0.8 inches)
  • Depth : 187 mm (7.4 inches)
  • Weight : 0.35 kg (0.77 lb)

ORDERING INFORMATION

Condition Monitoring Card CMC 16 200-530-SSS-HHh
