CP751 High-quality Dynamic Pressure Sensor

High-quality Dynamic Pressure Sensor

item no.:
CP751
lead time:
12-18 weeks
product orgin:
Switzerland
shipping port:
Xiamen
payment:
T/T
Condition:
New

contact now

product details

CP751 KEY FEATURES AND BENEFITS

• From the vibro-meter ® product line
• Operating temperature range:−40 to 700 °C
• Pressure sensitivity: >120 pC/bar
• High-pressure capability: up to 350 bar
• Frequency response: 2 to 10 000 Hz
• Ex certified for use in hazardous areas(potentially explosive atmospheres)
• Single-crystal piezoelectric material
• Integral mineral-insulated (MI) cable
• Versions with additional cable protection

CP751 MECHANICAL

Weight

- Sensor head : 20 g (0.044 lb) approx.

- MI cable : 50 g/m (0.034 lb/ft) approx.

- Connector : 20 g (0.044 lb) approx.

Cable : Mineral-insulated (MI) cable, two conductors.Versions with additional cable protection (overbraid) available.

Connection : vibro-meter® high-temperature or LEMO type 0 connector

CP751 MECHANICAL DRAWINGS

CP751 ORDERING INFORMATION

*CP751 Dynamic pressure sensor-with vibro-meter® LEMO type 0 connector

1 m (39.4″) ：143-751-000-011
2 m (78.7″) ：143-751-000-021
3 m (118.1″) ：143-751-000-031
5 m (196.9″) ：143-751-000-041
12.5 m (492.1″) ：143-751-000-051

*CP751 Dynamic pressure sensor with vibro-meter® high-temperature connector

1 m (39.4″) ：143-751-000-111
2 m (78.7″) ：143-751-000-121
3 m (118.1″) ：143-751-000-131
5 m (196.9″) ：143-751-000-141
12.5 m (492.1″) ：143-751-000-151

*CP751 Dynamic pressure sensor with Vibro-meter® high-temperature connector and cable protection (overbraid)

1 m (39.4″) ：143-751-000-211
2 m (78.7″) ：143-751-000-221
3 m (118.1″) ：143-751-000-231
5 m (196.9″) ：143-751-000-241
12.5 m (492.1″) ：143-751-000-251

CP751 ACCESSORIES

MA104 mounting adaptor for CP751 with vibro-meter® LEMO type 0 connector 809-104-000-011
MA seal MA internal pressure seal 143-215-902-011
Cable assemblies
