CPUM 200-595-074-422 Modular CPU Card

Modular CPU Card

item no.:
200-595-074-422
lead time:
1-3 days
product orgin:
Switzerland
shipping port:
Xiamen
payment:
T/T
Condition:
New

contact now

product details

CPUM 200-595-074-422 FEATURES

From the Vibro-Meter® product line
One-Shot’configuration of all VM600 cards using a direct Ethernet or RS-232 serial connection from an external computer, such as a laptop, notebook or industrial PC, running the VM600 MPSx software
Local micro-display for visualisation of monitored outputs and alarm limits
Two Ethernet connections and up to three serial connections (RS-232/RS-422/RS-485) can be accommodated simultaneously
External communication interfaces with third party devices such as a DCS or PLC
Industry standard protocols including Modbus RTU and Modbus TCP
Redundant communications links can beconfigured to improve availability
VM600 MPS rack (CPUM) security
Extended operating range of −20 to 70°C

CPUM 200-595-074-422 CPU module

Module type : PFM-541I or equivalent
Processor type : AMD Geode™ LX800
Processor speed : 500 MHz
Memory : 256 MB DRAM
Power supply : +5 VDC, <1.8 A
Operating system : QNX
Note: The CPU module is fitted to all versions of the CPUM card.

CPUM 200-595-074-422 Physical

Height : 6U (262 mm, 10.3″)
Width : 40 mm (1.6″)
Depth : 187 mm (7.4″)
Weight : 0.40 kg (0.88 lb) approx.

CPUM Ordering number

– Ethernet redundant
Modular CPU card with a CPU module that supports two Ethernet interfaces and two serial interfaces.
This CPUM supports Ethernet interfaces on the front panel (CPUM) and the rear panel (IOCN), a serial interface (RS-232) on the front panel (CPUM) and a serial interface (isolated RS-232/RS-485) on the rear panel (IOCN).
A front panel display and an operating system licence are also included.

601-003-000-VVV\3\610-1CC-CCC

(equivalent to a 200-595-0Ss-33h with a configuration)

– Ethernet redundant varnished
Same as the Ethernet redundant version, with a conformal coating for additional environmental protection.

601-003-000-VVV\3V\610-1CC-CCC

(equivalent to a 200-595-0Ss-33hl with a configuration)

– Serial redundant
Modular CPU card with a CPU module that supports two Ethernet interfaces and two serial interfaces, and a serial communications module that supports additional serial interfaces.
This CPUM supports Ethernet interfaces on the front panel (CPUM) and the rear panel (IOCN), a serial interface (RS-232) on the front panel (CPUM) and a serial interface (isolated RS-232/RS-485) on the rear panel (IOCN). It also supports two additional serial interfaces(RS-422/RS-485) on the rear panel (IOCN).
A front panel display and an operating system licence are also included.
