DIC 413 De-icing Controller with the EW 140 Ice Sensor

De-icing controller

item no.:
DIC 413
lead time:
1-3 days
product orgin:
Switzerland
shipping port:
Xiamen
payment:
T/T
Condition:
New

contact now

product details

*Operating principle :

Conversion of current-modulated sensor signal into an analog voltage

*Power requirements :

+22 to +30 VDC (+24 VDC nominal).
Within this range, maximum current consumption is 100 mA.

*Connection to EW 140 ice sensor :

Via an EC 119 cable assembly (length 5 m), JB 116 junction box and a customer supplied field cable (2-core, twisted, shielded cable with maximum length 150 m)

Outputs

F/V output (frequency-to-voltage)
• Function : Analog voltage providing an indication of ice thickness.
Seethe Typical transfer function curve for details.
• Output impedance : 1 kΩ
Discrete outputs (relays)
• OK output : Relay driven by the DIC 413 controller’s built-in test circuitry
• ICE ALARM output : Relay switched when the pre-selected ice thickness is exceeded

Mechanical

*Enclosure : Sealed two-part (housing and cover) die-cast aluminium enclosure with protective coating

*Protective coating : Multi-component treatment produces an (elastic) enamel that is resistant to rubbing and scratching, and provides resistance against chemicals and corrosion. Suitable for use under extreme conditions.

*Cover seal (gasket) : Silicone rubber (VMQ), resistant to weathering, ozone, chemicals and oils.

*Mounting : Four Allen screws, size M6 x 30 mm, in stainless steel

*Protection rating : IP65, according to IEC 60529 (corresponds to NEMA type 12)

*Dimensions : See Mechanical drawings

*Weight : Max. 2.2 kg (4.85 lb)

System Overview

Mounting Accessorie

JB 116 Junction box

Mechanical Drawings
