EMERSON SE4302T01 DO 24V DC High-Side丨Low Voltage Instrumentation CHARMs

EMERSON Low Voltage Instrumentation CHARMs

  • item no.:

    SE4302T01

  • lead time:

    2-3 weeks

  • product orgin:

    Switzerland

  • shipping port:

    Xiamen

  • payment:

    T/T

  • price:

    $600/660

  • market price:

    $600

  • Condition:

    New
  • product details

SE4302T01 SPECIFICATIONS

A high-side digital output Characterization Module (CHARM) for 24 V DC Solenoid coils.

  • Device Type24 V DC Solenoid coils
  • On State Output rating100 mA continuous @ 24 V DC
  • Off-state Leakage Current1 mA maximum
  • Line Fault DetectionGuaranteed short circuit: <50 Ω Load, Guaranteed good status: 240 Ω to 10 kΩ load, Guaranteed open circuit: >20 kΩ load
  • Configurable Output BehaviorMomentary Output, Continuous Pulse Output, Line fault testing
  • Line Fault Test Timing200 µsec
  • Field Circuit Protection200 mA Current Limiting Circuit, Field wiring disconnect
  • CHARM power req.116 mA max @ 24 V DC - Standard Terminal Block, 24 mA max @ 24 V DC - Relay Output Terminal Block
  • CHARM Heat DissipationPulse Count - Pulse train 0.1 Hz to 10 KHz, 50 µsec min pulse width

SE4302T01 Features



  • Eliminate marshalling and add I/O anywhere in the plant without affecting control room cabinets
  • No marshalling cabinet or cross-wiring, fewer wires, much less work and fewer contact points for potential failures
  • No marshalling cabinet or cross-wiring, fewer wires, much less work and fewer contact points for potential failures

Relevant Low Voltage Instrumentation CHARMs


DI NAMUR SE4301T01
DI 24V DC Low-Side Sense (Dry Contact) SE4301T02
DI 24V DC Isolated SE4301T07
DO 24V DC High-Side SE4302T01
DO 24V DC Isolated SE4302T02
DO 24V DC 100mA Energy Limited SE4302T04
24V DC Power SE4302T05
AI 4-20 mA HART SE4303T01
Thermocouple/mV Input SE4303T02
RTD Input SE4303T03
AI 0-10V DC Isolated SE4303T04
AO 4-20 mA HART SE4304T01
