GE Fanuc IC698CPE010 Processor Module CPU
GE Fanuc IC698CPE010 Processor Module CPU 100% Brand New. 365 days warranty.
item no.:
IS200STAIH2Alead time:
2-3 work daysproduct orgin:
USAshipping port:
Xiamen Chinapayment:
T/Tmarket price:
$999price range:
1-999/1$color:
Depends on the materialCondition:
NewSimplex Analog I/O(STAI) Terminal Board
The STAI terminal board is a compact analog input terminal board that accepts 10 analog inputs and two analog outputs, and connects to the YAIC I/Opack.
The 10 analog inputs accommodate two-wire, three-wire, four-wire, or externally powered transmitters.
The analog outputs are configured for 0 to 20 mA. An on-board ID chip identifies the board to the I/Opack for system diagnostic purposes.
The TBAI terminal board is an analog input terminal board used in TMR and Simplex configurations that supports 10 analog inputs and two outputs, and connects to the YAIC I/Opack. The 10 analog inputs accommodate two-wire, three-wire, four-wire, or externally powered transmitters.
The analog outputs can be configured for 0 to 20 mA. Inputs and outputs have noise suppression circuitry to protect against surge and high frequency noise. The TBAI has three DC-37 pin connectors for three TMR I/Opacks or one Simplex I/Opack.
The Analog I/OTerminal Board with YAIC I/OPack Specifications table provides the specifications for the Analog I/Oterminal boards available for use in the Mark VIeS Functional Safety System.
For more information on the YAIC I/Opack and the STAI
and TBAI terminal boards, refer to the chapter “PAIC, YAIC Analog I/O Modules” in the
document Mark VIeS Functional Safety Systems for General Market Volume II: System Guide
for General-purpose Applications .
The STAI plus a plastic insulator mounts on a sheet metal carrier that then mounts on a DIN-rail.
Optionally, the STAI plus insulator mounts on a sheet metal assembly and then bolts directly to a cabinet.
There are two types of Euro-block terminal blocks available as follows:
• STAIH1 has a permanently mounted terminal block with 48 terminals
• STAIH2 has a right angle header accepting a range of commercially available pluggable terminal blocks, with a total of 48 terminals
Typically #18 AWG wires (shielded twisted pair) are used. I/O cable shield terminal is provided adjacent to the terminal blocks. The following types of analog inputs and outputs can be accommodated:
• Analog input, two-wire transmitter
• Analog input, three-wire transmitter
• Analog input, four-wire transmitter
• Analog input, externally powered transmitter
• Analog input, voltage ±5 V, ±10 V dc
• Analog output, 0-20 mA current
• Analog output, 0-200 mA current
The following I/O pack and terminal board combinations are approved for use in hazardous locations:
• Mark VIe Analog I/O pack IS220PAICH1A
with terminal boards (accessories) IS200STAIH1A, IS200STAIH2A, or IS200TBAIH1C
• Mark VIe Analog I/O pack IS220PAICH1B
with terminal boards (accessories) IS200STAIH1A, IS200STAIH2A, or IS200TBAIH1C
• Mark VIeS Safety Analog I/O pack IS220YAICS1A
with terminal boards (accessories) IS200STAIS1A, IS400STAIS1A, IS200STAIS2A, IS400STAIS2A, IS200TBAIS1C, or IS400TBAIS1C
• Mark VIeS Safety Analog I/O pack ISx2yYAICS1B (where x = 2 or 4 and y = 0 or 1)
with terminal boards (accessories) ISx0ySTAIS1A, ISx0ySTAIS2A, or ISx0yTBAIS1C
