GE Fanuc IC698CPE010 Processor Module CPU
GE Fanuc IC698CPE010 Processor Module CPU 100% Brand New. 365 days warranty.
item no.:
IS230PCAAH1Blead time:
1-3 daysproduct orgin:
Switzerlandshipping port:
Xiamenpayment:
T/TCondition:
NewGeneral Electric GE Mark VIe Core Analog I/O Model IS230PCAAH1B
Part Number: IS230PCAAH1B
Manufacturer: GE General Electric
Type: Mark VIe
Product Type: I/O Module
Number of Inputs: 25
Number of Outputs: 4-20 mA
Analog 0-10 V DC Inputs: ±0.50%
LVDT Excitation Monitor Input: ±1.00%
Servo Driver Output: ±3.50%
Power Supply Input Voltage: 28Vdc±5%
Operating Temperature: -30 to 65oC
Product of Origin: USA
Manual: GEH-6721L
PCAA Core Analog
*The two application I/O boards, the terminal board, and the processor board shared by all Mark* VIe distributed I/O are all included in the PCAA, and the various boards that make up the module are not supported for diagnostics or replacement. The entire module is the least modified component.
*Dual RJ45 Ethernet connectors and 28V DC power connector P5 are used to supply input to the module. Euro-style 120 box terminals are located at the end of the module and provide power to the field device I/O. JGPA board. Two 68-pin cables with connectors P1 and P2 are used to connect the module to the TCAT.
*The PCAA separates signals into two categories. The TCAT terminal board is used to route signal inputs that can be fanned from a single input to a single, dual, or TMR PCAA module. The terminals on the PCAA are wired with dedicated signals. Using a single PCAA module produces the signal divisions in the following table: If you don't need a fanned input, you can use a PCAA instead of a TCAT.
Compatibility
PCAA
Quantity
IONet
Commections
Frame
Rate
TCAT
Connections
Comments
Simplex
One or Two
40 ms
Zero or One
TCAT optional on simplex configurations
Simplex
One
10 ms
Zero or One
Only one IONet at 10 msec frame rates
TMR
One
40 ms
One
TMR configurations only support one IONet per PCAA
TMR
One
10 ms
One
Operation
The PCAA module is a physical assembly made up of four different circuit boards. Because it is challenging to narrow down a failure to a specific board, the module is thought of as the least replaceable component. Individual boards cannot be replaced with the module.
