GE Fanuc IC698CPE010 Processor Module CPU
GE Fanuc IC698CPE010 Processor Module CPU 100% Brand New. 365 days warranty.
item no.:
IS200TRLYH1Blead time:
1-3 daysproduct orgin:
USAshipping port:
Xiamenpayment:
T/Tprice:
$1/999Condition:
NewPart No.: IS200TRLYH1B
Manufacturer: General Electric
Country of Manufacture: USA
Product Type: Termination Relay Card
Series: Mark VIe
The IS200TRLYH1B is a Relay Output Terminal Board developed by GE under the Mark VIe series.
There are 12 plug-in magnetic relays on the Relay Output with Coil Sensing (TRLY1B) terminal board.
The first six relay circuits can be set up with jumpers to drive external solenoids or dry, Form-C contact outputs.
For field solenoid power, a basic 125 V dc or 115/230 V ac source or an optional 24 V dc source with personal jumper-selectable fuses and onboard suppression can be offered.
The next five relays (7–11) are isolated Form-C contacts that are not powered.
An isolated Form-C contact is used on output 12 for specialized uses like ignition transformers.
On the left edge of the board are huge black terminal blocks.
Each terminal block contains twenty-four silver metal terminals.
There are a total of 48 terminals in all. On the terminal blocks, each terminal has been designated in white type.
On the right side of the board, there are four connector ports.
Three connector ports are vertically aligned on the edge, while the fourth sits parallel to the connector port at the bottom.
A transistor is located on both sides of each relay.
A circular red MOV, or metal oxide varistor, is paired with each transistor. On the upper part of the board, five of these relays are vertically aligned.
On the lower portion of the PCB, five more relays have been aligned.
| IS200EACFG3BAA | IS200TDBTH2ACC | IS200VTCCH1CBB | IS220PPRFH1A | IS230SNAOH2A |
| IS200EBKPG1C | IS200TDBTH6ABC | IS200VTURH1BAA | IS220PPROH1A | IS230SNRLH2A |
| IS200EDCFG1BAA | IS200TDBTH6ACD | IS200VTURH1BAB | IS220PRTDH1A | IS230TNPAH2A |
| IS200EDEXG1B | IS200TPROH1BBB | IS200VTURH2B | IS220PSCAH1A | IS230TPROH3C |
| IS200EHPAG1D | IS200TPROH1CAA | IS200VVIBH1CAB | IS220PTCCH1A | IS215VCMIH2BB |
| IS200EPBPG1A | IS200TREGH1BDB | IS2020RKPSG2A | IS220PTURH1A | IS215VCMIH2BC |
| IS200EPCTG1AAA | IS200TRLYH1BED | IS2020RKPSG3A | IS220PTURH1B | IS200TTURH1B |
| IS200EPSMG2AEC | IS200TRLYH1BFD | IS210BAPAH1A | IS220PVIBH1A | IS200TTURH1BCC |
| IS200ERBPG1ACA | IS200TRLYH1BGF | IS215UCCCM04A | IS220UCSAH1A | IS200EXHSG3AEC |
| IS200ERDDH1ABA | IS200TRLYH1BGG | IS215UCVDH7A | IS220YAICS1A | IS200JPDEG1A |
| IS200ERIOH1AAA | IS200TRPAH2AHE | IS215UCVEH2A | IS220YDOAS1A | IS215VAMBH1ADX |
| IS200EROCH1ABB | IS200TRPGH1BCC | IS215UCVEH2AE | IS200ESELH2AAA | IS200TSVOH1BBB |
| IS200ERSCG1AAA | IS200TRTDH1CCC | IS215VAMBH1A | IS420UCSBH3A | IS420UCSCH1A |
| IS400JPGPA1ACD | IS400TCASH1AGD | IS415UCVHH1A | IS420UCSCS2A | IS420UCSCH1B |
| IS200WNPSH1A | IS400JPDMG1A | IS200EAUXH1A | IS420UCSCH1B | IS420UCSBH3A |
