GE Fanuc IC698CPE010 Processor Module CPU
GE Fanuc IC698CPE010 Processor Module CPU 100% Brand New. 365 days warranty.
item no.:
IS200TSVCH1Alead time:
5-7 DAYSproduct orgin:
USAshipping port:
XIAMEN, CHINApayment:
T/Tcolor:
DEPENDING ON THE MATERIALGE IS200TSVCH1A Functional Description
The Servo Input/Output (TSVC) terminal board interfaces to two electro-hydraulic servo valves that actuate the steam/fuel valves. Valve position is measured with linear variable differential transformers (LVDT). TSVC is designed specially for the PSVO I/O pack and the WSVO servo driver, and will not work with the VSVO processor.
The terminal board supports simplex, dual, and TMR control. Three 28 Vdc supplies come in through plug J28. Plugs JD1 or JD2 are for an external trip from the protection module.
Sensors and servo valves are wired directly to two I/O terminal blocks. Each block is held down with two screws and has 24 terminals accepting up to #12 AWG wiring. A shield terminal strip attached to chassis ground is located immediately to the left of each terminal block. External trip wiring is plugged into either JD1 or JD2. Each servo output can have three coils in TMR configuration. The size of each coil current is jumper selected using JP1, 3, 5 for Servo 1, and JP2, 4, 6 for servo 2.
PSVO makes diagnostic checks on the terminal board components as follows:
• The output servo current is out of limits or not responding, creating a fault.
• The regulator feedback (LVDT) signal is out of limits, creating a fault. If the associated regulator has two sensors, the bad sensor is removed from the feedback calculation and the good sensor is used.
• If any one of the above signals go unhealthy a composite diagnostic alarm,L#DIAG_PSVO occurs. Details of the individual diagnostics are available from the ToolboxST* application. The diagnostic signals can be individually latched,and reset with the RESET_DIA signal if they go healthy.
• Each cable connector on the terminal board has its own ID device that is interrogated by the I/O processor. The ID device is a read-only chip coded with the terminal board serial number, board type, revision number, and the J connector location. When this chip is read by the I/O processor and a mismatch is encountered, a hardware incompatibility fault is created.
• Servo control I/O pack IS220PSVOH1A
• Terminal board (accessory) IS200TSVCH2A
• Servo driver (accessory) IS210WSVOH1A
• Servo control I/O pack IS220PSVOH1B
• Terminal board (accessory) IS200TSVCH2A
• Servo driver (accessory) IS410WSVOH1A
