GE IS220PPDAH1B Mark VIe Discrete Output Modules

GEMark VIe Discrete Output Modules

  • item no.:

    IS220PPDAH1B

  • lead time:

    1-3 days

  • product orgin:

    USA

  • shipping port:

    Xiamen

  • payment:

    T/T

  • Condition:

    New
  • product details

Part Number: IS220PDIAH1B

Manufacturer: GE

Product Type: Discrete Contact Input Terminal Board

Function: I/O Module

Series: Mark VIe

Size: 8.26 cm high x 4.19 cm wide x 12.1 cm deep

Weight: 0.8kg

Country of Origin: USA

Manual: GEH-6721D

Functional Description



      The Discrete Output IS220PDIAH1B provides the electrical interface between one or two I/O Ethernet networks and a discrete output terminal board.

       IS220PDIAH1B contains a processor board common to all Mark* VIe distributed I/O packs and an acquisition board specific to the discrete output function.

      IS220PDIAH1B is capable of controlling up to 12 relays and accepts terminal board specific feedback.

      Electromagnetic relays (with types TRLYH1B, C, D, and F terminal boards) and solid-state relays (with type TRLYH1E boards) are available.

       Input to the pack is through dual RJ45 Ethernet connectors and a three-pin power input.

Output is through a DC-37 pin connector that connects directly with the associated terminal board connector.

Visual diagnostics are provided through indicator LEDs.

Compatibility



     IS220PDOAH1B is compatible with six types of discrete (relay) output terminal boards, including the TRLY boards and SRLY boards, but not the DIN-rail mounted DRLY boards.

Control mode refers to the number of I/O packs used in a signal path:
• Simplex uses one I/O pack with one or two network connections.
• Dual uses two I/O packs with one or two network connections.
• TMR uses three I/O packs with one network connection on each pack.
Operation

The processor board is common to all Mark VIe Ethernet I/O packs or modules. It contains the following:
• High-speed processor with RAM and flash memory
• Two fully independent 10/100 Ethernet ports with connectors
• Hardware watchdog timer and reset circuit
• Internal temperature sensor
• Status-indication LEDs
• Electronic ID and the ability to read IDs on other boards
• Input power connector with soft start/current limiter
• Local power supplies, including sequencing and monitoring
Relay Command Signals


       The PDOA relay command signals are the first stage of signal conditioning and level shifting to interface the terminal board outputs to the control logic. Each output is an open collector transistor circuit with a current monitor to sense when the output is picked up and connected to a load. The status LEDs and monitor outputs indicate when an output is picked up and connected to the terminal board. If an output is picked up and the correct load is not sensed, the status LED will be off and the monitor line will be false.
