XIO16T 620-002-000-113 Input/output Module New in stock For XMx16
Input/output Module
item no.:
IQS452lead time:
2-3 work daysproduct orgin:
Switzerlandshipping port:
Xiamen Chinapayment:
T/Tcolor:
Depends on the materialCondition:
New
|
Switzerland |
|
IQS452 |
|
New |
|
12 months |
*Measuring range: 2 mm or 4 mm
*Transducer temperature range: -40°C to +180°C
*Sensitivity:
-4 mV/μm or 8 mV/μm
-1.25 /μm or 2.5 μA/μm
*Frequency response: DC to 20 kHz(-3 dB)
• Using IQS 452 Version 0XX : 4 mV/μm (100 mV/mil)
• Using IQS 452 Version 1XX : 1.25 μA/μm (31.2 μA/mil)
• Using IQS 452 Version 2XX : 8 mV/μm (200 mV/mil)
• Using IQS 452 Version 3XX : 2.5 μA/μm (62.5 μA/mil)
• Using IQS 452 Version 2XX or IQS 452 Version 3XX
0.15 - 2.15 mm, corresponding to
-1.6 V to -17.6 V output using IQS 452 Version 2XX
15.5 mA to 20.5 mA output using IQS 452 Version 3XX
• Using IQS 452 Version 0XX or IQS 452 Version 1XX
0.3 - 4.3 mm, corresponding to
-1.6 V to -17.6 V output using IQS 452 Version 0XX
15.5 mA to 20.5 mA output using IQS 452 Version 1XX
Order Informations
| IQS Type |
Measuring
Range
|
Mode | Sensitivity |
Total System
Length
|
Version | Ordering Number |
|
IQS 452 versions
M0XX or M1XX
|
4 mm |
Voltage output,
3-wire configuration
|
4 mV/μm |
5 m
10 m
5 m
10 m
|
Standard
Standard
Exi
Exi
|
204-452-000-01
204-452-000-02
204-452-000-03
204-452-000-04
|
|
Current output,
2-wire configuration
|
1.25 μA/μm |
5 m
10 m
5 m
10 m
|
Standard
Standard
Exi
Exi
|
204-452-000-11
204-452-000-12
204-452-000-13
204-452-000-14
|
||
|
IQS 452 versions
M2XX or M3XX
|
2 mm |
Voltage output,
3-wire configuration
|
8 mV/μm |
5 m
10 m
5 m
10 m
|
Standard
Standard
Exi
Exi
|
204-452-000-21
204-452-000-22
204-452-000-23
204-452-000-24
|
|
Current output,
2-wire configuration
|
2.5 μA/μm |
5 m
10 m
5 m
10 m
|
Standard
Standard
Exi
Exi
|
204-452-000-31
204-452-000-32
204-452-000-33
204-452-000-34
|
Accessories
JB 118 Junction box PA 153 Probe adapter
PA 151 Probe adapter SG 102 Cable feedthrough
PA 152 Probe adapter
