PA153 800-153-000-111 Probe Mounting Adaptor

Probe Mounting Adaptor

item no.:
800-153-000-111
lead time:
1-3 days
product orgin:
Switzerland
shipping port:
Xiamen
payment:
T/T
Condition:
New

product details

PA153 800-153-000-111 KEY FEATURES AND BENEFITS

• From the vibro-meter® product line
• For the external mounting of TQxxx proximity sensors
• Stainless steel rod available in lengths from 50 to 800 mm, with mounting position adjustable to ±10 mm
• Range of adaptor threads and lengths
• Choice of cable fitting (stuffing gland) options

PA153 800-153-000-111 APPLICATIONS

• For use with TQxxx proximity measurement chains/systems
• Allows easier probe (sensor) installation and gap adjustment

PA153 800-153-000-111 DESCRIPTION

The PA153 probe mounting adaptor is designed for use with TQxxx proximity measurement chains/ systems, from Meggitt’s vibro-meter® product line.

The PA153 probe mounting adaptor allows the external mounting of a reverse-mount proximity sensor such as the TQ912, without the need for machine disassembly. The probe mounting adaptor makes it easier to adjust the gap or replace the sensor, even while the machine is running.

Designed for harsh industrial environments, the adjustable stainless-steel rod protects the proximity sensor and the sensor to extension cable connection.

The PA153, together with matching cable and cable feedthroughs makes installation easier and heps ensure the proper functioning of a proximity measurement chain/system.

For specific applications, contact your local Meggitt representative.

PA153 800-153-000-111 ORDERING INFORMATION

PA153 800-153-000-111 Datasheet Download
