PSB990 200-582-990-NHH Two DC inputs with Screw-terminal Connectors

Two DC inputs with Screw-terminal Connectors

item no.:
200-582-990-NHH
lead time:
12-18 weeks
product orgin:
Switzerland
shipping port:
Xiamen
payment:
T/T
Condition:
New

product details

(d) Special DC version (ordering number (PNR): PSB990 200-582-990-NHH )

This version has two screw-terminal connectors for the DC power inputs, intended for the connection of two independent DC mains supplies. Both inputs (connectors) are wired to the same point on the VM600Mk2/VM600 rack backplane through protection diodes, which allows the rack to continue operating if one of the DC mains supplies becomes defective. The wiring assembly for the rear panel includes the additional cabling ( ) only when both RPS6U rack power supplies (PS1 and PS2) are AC-input versions operating with DC inputs (which requires a rear panel with a DC input).

ORDERING INFORMATIO

To order, specify a type (Rear panel), designation and ordering number (PNR) from the table below. When ordering a rear panel with a DC input – (a), (b), (c), (d) or (m) – it is also necessary to specify the voltage/ version of the associated RPS6U rack power supply or supplies (24 VDC (RPS6U 24 DC), 110 VDC (RPS6U 110 DC) and/or 178 to 264 VDC (RPS6U AC)) in order that the correct version of the rear panel is supplied.

200-582-920-NHh

200-582-993-NHh

200-582-922-NHh

200-582-990-NHh

200-582-910-NHh

200-582-911-NHh

200-582-912-NHh

200-582-962-NHh

200-582-963-NHh

200-582-960-NHh

200-582-915-NHh

200-582-916-NHh

200-582-970-NHh
