IOC4T 600-043 Machinery Protection and Condition Monitoring Module

Designed for operation with the second generation of VM600Mk2 rack-based machinery protection system.

The VM600Mk2 MPC4Mk2 + IOC4Mk2 module consists of processing and input/output (interface) modules that provide 4 dynamic and 2 auxiliary channels of machinery protection and optional condition monitoring in VM600Mk2 systems.

IOC4T 600-043 Product Information

The VM600 MPC4 600-041 +IOC4T 600-043  machinery protection and condition monitoring module provides:
  4 dynamic channels and 2 auxiliary channels of machinery protection and condition monitoring.
  4 user-configurable relays for alarms and 1 common-circuit fault relay.
  Diagnostics (BIST) with system-wide safety line to drive all associated protection system relays and analog outputs to a safe state.

IOC4T 600-043 KEY FEATURES AND BENEFITS

• VibroSight® compatible hardware from the vibro-meter® product line

• VM600Mk2 (second generation) machinery protection and condition monitoring module

• 4 dynamic channels and 2 auxiliary channels configurable as either tachometer inputs or DC inputs

• VM600Mk2 system safety-line to drive all system relays to a safe state

• Diagnostics (built-in self-test (BIST)) provides continuous feedback on the health of the module

• Individually configurable inputs (with sensor power supply outputs), channel filters,processing and outputs – with simultaneous data acquisition (fixed frequency order tracking)

• High-resolution spectra (FFT) for condition monitoring: up to 6400 lines every 100 ms

• Up to 10 processed outputs per channel

• Multiple alarms per processed output with configurable limits, hysteresis and time dela

• AND, OR and majority voting logic functions for the combination of alarm and status information

• Discrete outputs: 4 user-configurable relays for use by alarms and 1 status relay

• Analog outputs: 4 outputs configurable as either 4 to 20 mA or 0 to 10 V

• Conforms to API 670

• Direct system Ethernet communications

• Compatible with VM600Mk2 system racks (ABE04x) and slimline racks (ABE056)

IOC4T 600-043 APPLICATIONS

• VM600Mk2 machinery protection (MPS) and/or condition monitoring (CMS)

• Vibration and/or combustion monitoring
• API 670 applications

MPC4 600-041 +IOC4T 600-043 Supported sensors

Currently available : Compatible with a wide range of sensors and measurement chains with current (2-wire) or voltage (3-wire) outputs, including the following sensors from the Meggitt vibro-meter® product line:

• CAxxx vibration sensors (piezoelectric accelerometers)
• CExxx and PVxxx vibration sensors (piezoelectric accelerometers and velocity sensors)
• CVxxx and VExxx vibration sensors (velocity sensors)
• CPxxx dynamic pressure sensors (piezoelectric pressure sensors)
• TQxxx proximity sensors
• LSxxx air-gap sensors.

IOC4T 600-043 Physical

IOC4Mk2

-Height : 6U (262 mm, 10.3 in)

-Width : 20 mm (0.8 in)

-Depth : 125 mm (4.9 in)

-Weight : 0.31 kg (0.68 lb) approx.

IOC4T 600-043 RELATED PRODUCTS

ABE04x -VM600Mk2/VM600 system racks

ABE056 -VM600Mk2/VM600 slimline rack

CPUMMk2 + IOCNMk2 -VM600Mk2 rack controller and communications interface module

RLC16Mk2 VM600Mk2 -relay module

XMx16 + XIO16T -VM600Mk2/VM600 condition monitoring module
