VSB300 601-009-A0 Monitoring Module丨Terminal base for a VSV30x module

VSB300 601-009-A0 KEY FEATURES AND BENEFITS

• VibroSight® compatible hardware from the vibro-meter® product line

• 2 individually configurable dynamic input channels with up to 19 kHz bandwidth

• 1 auxiliary input channel configurable as either a tachometer or a DC input

• Synchronous sampling of input channels

• Up to 20 configurable processed outputs per module

• Spectrum analyzer (FFT) up to 1600 lines every 100 ms

• Up to 4 alarms per processed output, with hysteresis and time delay

• AND, OR and majority voting logic functions for the combination of alarm and status information

• VibroSmart® security (module lock)

• Redundant communications and redundant power supply inputs to improve availability

• Analog outputs: 2 local outputs configurable as 4-20 mA or ±5 V

• Discrete outputs: 2 local relays

• Real-time Ethernet communications

• Live insertion and removal of modules (hotswappable) with automatic reconfiguration

• Fully software configurable

• Robust enclosures with DIN rail mounting

• Vibration and/or combustion monitoring

• Machinery protection and/or condition monitoring

• Conforms to IEC 61850-3 requirements for power plant and utility applications

VSB300 601-009-A0 Monitoring Module

      The VSV301 monitoring module performs the data acquisition and all of the signal processing(filtering, analog-to-digital conversion, time andfrequency domain processing, and resampling)required to produce processed outputs and extracted data for physical output and data presentation in VibroSight and VibroSight Scope.
      This includes spectral band extractions,advanced FFT analysis, trending and limit checks (alarm and sensor OK), and run-up / run-down acquisition.
      In addition, the VSV301 module has four basic and two advanced logic functions that can be used to combine local alarm and status information in order to drive the module’s relays.
      This local information and the logic function outputs can also be used as inputs to the basic logic functions of a VSI010 communications interface module in the same measurement block.
      Like all VibroSmart modules, the VSV301 module is fully software configurable using the VibroSight software.
      Using VibroSight Configurator, a module can be configured to capture data continuously at scheduled intervals or on the detection of an alarm condition.
      In addition, spectral resolution,frequency bandwidth, windowing function and averaging are all fully configurable.
      Using VibroSight Vision, an extensive catalogue of plots is available for the visualisation and analysis of measurement data.

• VSB300 terminal base : 550 g (1.21 lb) approx.
• Module mounting :

The VSV301 module clips into the VSB300 terminal base, which mounts on a TH 35 DIN rail (according to EN 50022 / IEC 60715). For example, TH 35-7.5 or TH 35-15.

• Connection to a host computer :

Ethernet connectors Eth1 and Eth2 allow connections to a host computer or network, using twisted-pair Ethernet cable

VSV301 VibroSmart monitoring module 600-034

VSB300 Terminal base for a VSV30x module 600-009

• VSA001 - 975.51.54.0030

T30 Torx driver with a length of 150 mm(suitable for the DIN rail adaptor in VSBxxx terminal bases)

• VSA002 - 934-129-000-011

Cable assembly for use with the buffered outputs (J2) of a VSV30x + VSB300, terminated with male BNC connectors for use as flying leads

• VSA003 - 934-128-000-011

Cable assembly for use with the buffered outputs (J2) of a VSV30x + VSB300, terminated with female BNC connectors for use with a patch panel

• VSK002 - 622-007-200-001

Set of 6 × terminal base BCF plug-in connectors for J1 to J6 (labelled and mechanically key-coded for a VSV30x + VSB300)

VSB300 Terminal Base – Front and Rear Views
