XIO16T 620-002-000-113 Input/output Module New in stock For XMx16
Input/output Module
item no.:
600-034lead time:
2-3 work daysproduct orgin:
Japanshipping port:
Xiamen Chinapayment:
T/Tmarket price:
$999price range:
1-999/1$color:
Depends on the materialVSV301 600-034 KEY FEATURES AND BENEFITS
• VibroSight® compatible hardware from the vibro-meter® product line
• 2 individually configurable dynamic input channels with up to 19 kHz bandwidth
• 1 auxiliary input channel configurable as either a tachometer or a DC input
• Synchronous sampling of input channels
• Up to 20 configurable processed outputs per module
• Spectrum analyzer (FFT) up to 1600 lines every 100 ms
• Up to 4 alarms per processed output, with hysteresis and time delay
• AND, OR and majority voting logic functions for the combination of alarm and status information
• VibroSmart® security (module lock)
• Redundant communications and redundant power supply inputs to improve availability
• Analog outputs: 2 local outputs configurable as 4-20 mA or ±5 V
• Discrete outputs: 2 local relays
• Real-time Ethernet communications
• Live insertion and removal of modules (hotswappable) with automatic reconfiguration
• Fully software configurable
• Robust enclosures with DIN rail mounting
• Vibration and/or combustion monitoring
• Machinery protection and/or condition monitoring
• Conforms to IEC 61850-3 requirements for power plant and utility applications
VSV301 Monitoring Module
The VSV301 monitoring module performs the data acquisition and all of the signal processing(filtering, analog-to-digital conversion, time andfrequency domain processing, and resampling)required to produce processed outputs and extracted data for physical output and data presentation in VibroSight and VibroSight Scope.
This includes spectral band extractions,advanced FFT analysis, trending and limit checks (alarm and sensor OK), and run-up / run-down acquisition.
In addition, the VSV301 module has four basic and two advanced logic functions that can be used to combine local alarm and status information in order to drive the module’s relays.
This local information and the logic function outputs can also be used as inputs to the basic logic functions of a VSI010 communications interface module in the same measurement block.
Like all VibroSmart modules, the VSV301 module is fully software configurable using the VibroSight software.
Using VibroSight Configurator, a module can be configured to capture data continuously at scheduled intervals or on the detection of an alarm condition.
In addition, spectral resolution,frequency bandwidth, windowing function and averaging are all fully configurable.
Using VibroSight Vision, an extensive catalogue of plots is available for the visualisation and analysis of measurement data.
The VSV301 module clips into the VSB300 terminal base, which mounts on a TH 35 DIN rail (according to EN 50022 / IEC 60715). For example, TH 35-7.5 or TH 35-15.
Ethernet connectors Eth1 and Eth2 allow connections to a host computer or network, using twisted-pair Ethernet cable
VSV301 VibroSmart monitoring module 600-034
VSB300 Terminal base for a VSV30x module 600-009
T30 Torx driver with a length of 150 mm(suitable for the DIN rail adaptor in VSBxxx terminal bases)
Cable assembly for use with the buffered outputs (J2) of a VSV30x + VSB300, terminated with male BNC connectors for use as flying leads
Cable assembly for use with the buffered outputs (J2) of a VSV30x + VSB300, terminated with female BNC connectors for use with a patch panel
Set of 6 × terminal base BCF plug-in connectors for J1 to J6 (labelled and mechanically key-coded for a VSV30x + VSB300)
