Yokogawa AAI143-S00 Analog I/O Module

Yokogawa Analog I/O

item no.:
AAI143-S00
lead time:
2-3days
product orgin:
JAPAN
payment:
T/T
Condition:
new

product details

AAI143-S00 Specifications

Number of input channels: 16, isolated
Input signal: 4 to 20 mA
Allowable input current : 24 mA
Withstanding voltage : Between input and system: 1500 V AC, for 1 minute
Input resistance Power ON : 270 Ω (20 mA) to 350 Ω (4 mA)
Input resistance Power OFF : 500 kΩ or larger
Accuracy : ±16 µA
Data update period: 10 ms
Transmitter power supply : 19.0 V or higher (at 20 mA) 25.5 V or less (at 0 mA) (output current limit: 25 mA)
Setting of 2-wire or 4-wire transmitter: For each channel by setting pin
Drift due to ambient temperature change : ±16 µA/10 ˚C
Maximum current consumption : 230 mA (5 V DC), 540 mA (24 V DC)
Weight : 0.3 kg
External communication : Pressure clamp terminal, MIL connector cable, dedicated cable

AAI143-S00 Description

Model-AAI143-Analog Input Module (4 to 20 mA, 16-channel, Isolated)
Suffix Codes-S-Standard type
Suffix Codes-H-With digital communication (HART protocol)
Suffix Codes-5-With no explosion protection
Suffix Codes-E-With explosion protection
Suffix Codes-0-Basic type
Suffix Codes-3-With ISA Standard G3 option and temperature (-20 to 70 °C) option

Option Codes/K4A00 -With KS Cable Interface Adapter (For connecting AEA4D Terminal Board)
Option Codes/A4S00-With Pressure Clamp Terminal Block
Option Codes/A4S10-With Pressure Clamp Terminal Block (surge absorber)
Option Codes/A4D00-With Dual Pressure Clamp Terminal Block
Option Codes/A4D10-With Dual Pressure Clamp Terminal Block (surge absorber)
Option Codes/CCC01 -With Connector Cover for MIL Cable

AAI143-S00 DATASHEET DOWNLOAD
