YOKOGAWA ALR121-S53 Serial Communication Modules With no explosion protection

YOKOGAWA ALR121-S53 Communication Module

item no.:
ALR121-S53
lead time:
2-3 work days
product orgin:
Japan
shipping port:
Xiamen China
payment:
T/T
price:
$999
market price:
$999
price range:
1-999/1$
color:
Depends on the material
Condition:
NEW

contact now

product details

ALR121-S53 HARDWARE SPECIFICATIONS

Model：ALR121-S53
Interface：RS-422/RS-485
Connection method：Point-to-point (RS-422)/Multipoint (RS-485)
Communication function Half-duplex
Synchronization method Start-stop synchronization
Transmission speed 1200/2400/4800/9600/19200/38400 bps (*1)
Transmission code ASCII/binary
Character length 7/8 bits
Stop bit length 1/2 bits
Parity check None/even/odd
Lag time after data transmission 1 ms (The lag time to start receiving data again after data transmission.)
Transmission distance：Maximum 1200 m (total extended length)
I/O wiring：Cable with 3-pair shield, AKB161, or AKB162
Current consumption 0.5A
Weight 0.3 kg

ALR121-S53 OPERATING ENVIRONMENT

Hardware Requirements

The serial communication module runs on the following FCS.

AFV30S, AFV30D, AFV40S, AFV40D, AFV10S, AFV10D,

AFS30S, AFS30D, AFS40S, AFS40D,

AFG30S, AFG30D, AFG40S, AFG40D,

AFG81S, AFG81D, AFG82S, AFG82, AFG83S, AFG83D, AFG84S, AFG84D,

AFF50S, AFF50D

Software Requirements

The serial communication module runs on the control functions of the following FCS.

LFS1700 Control Function for Field Control Station (for AFV30/AFV40, Vnet/IP and FIO):for AFV30/AFV40

LFS1500 Control Function for Field Control Station (for AFV10, Vnet/IP and FIO): for AFV10

LFS1300 Control Function for Standard Field Control Station (for V net and FIO): for AFS30/AFS40

LFS1330 Control Function for Enhanced Field Control Station (for V net and FIO):for AFG30AFG40/AFG8

LFS1350 Control Function for Compact Field Control Station (for V net and FIO): for AFF50
