YOKOGAWA FLXA202-D-B-D-CB-P1-NN-A-N-LA-N-NN/U 2-Wire Analyzer Module

YOKOGAWA 2-Wire Analyzer

item no.:
FLXA202-D-B-D-CB-P1-
lead time:
2-3days
product orgin:
JAPAN
payment:
T/T
Condition:
new

product details

FLXA202-D-B-D-CB-P1-NN-A-N-LA-N-NN/U Features

4 kinds of measurements; pH/ORP, SC, ISC and DO
Dual sensor measurement on 2-wire type analyzer;pH/ORP and pH/ORP, SC and SC, and DO and DO
Calculated data from dual sensor measurement
Redundant system on dual sensor measurement
Connection of FU20F / FU24F / SC25F Digital pH/ORP SENCOM Sensor
Easy touch screen operation on 2-wire type analyzer
Simple HMI menu structure in 12 languages
Quick setup menu for immediate measurement
Indication of sensor wellness
Enclosure – aluminum alloy cast

FLXA202 Input Specification

The FLXA202 accepts output from membrane covered Dissolved Oxygen sensors. These sensors can be Galvanic type, where the sensor generates its own driving voltage or Polarographic type, where the sensor uses external driving voltage from the converter.
The input range is 0 to 50 µA for Galvanic sensors and 0 to 1 micro A for Polarographic sensors. For temperature compensation, the FLXA202 accepts Pt1000 (DO30 sensor) and NTC22k elements (OXYFERM and OXYGOLD sensors).

FLXA202 Suffix Codes

Power supply-D-Always -D
Housing-B-Aluminum alloy cast + urethane coating
Housing-C-Aluminum alloy cast + epoxy coating
Housing-D-Aluminum alloy cast + high anti-corrosion coating
Display-D-Anti-glare LCD
Type-AB-General purpose for CE, RCM
Type-AD-General purpose for CSA
Type-AG-General purpose for KC
Type-AQ-General purpose for EAC with PA (pending)
Type-AR-General purpose for EAC (pending)
Type-CB-IS for ATEX, IECEx
Type-CD-IS for FM, (CSA (pending)
Type-CF-IS for TIIS (pending)
Type-CH-IS for NEPSI (pending)
Type-CQ-IS for EAC with PA (pending)
Type-CR-IS for EAC (pending)
Type-DB-Type n for ATEX, IECEx (pending)
Type-DD-NI for FM, (CSA (pending))
Type-DE-Type n for CSA (pending)
