YOKOGAWA SCP451-11 PROCESSOR MOUDLE CPU
YOKOGAWA SCP451-11 PROCESSOR MOUDLE CPU 100% Brand New. 365 days warranty.
item no.:
FX1002-4-3-H/C2lead time:
2-3daysproduct orgin:
JAPANpayment:
T/TCondition:
newThe FX1000 (Model FX1002/FX1004/FX1006/FX1008/FX1010/FX1012) is a Paperless Recorder that displays real-time measured data on a color LCD and saves data on a CompactFlash memory card (CF card)*1 or SD card*2. It can be hooked up to network via Ethernet, which enables to inform by Email and to monitor on Web site as well as to transfer files by using FTP. Also, it can communicate with Modbus/RTU or Modbus/TCP. It comes with a two, four, six,eight, ten-channel or twelve-channel model. As the input signal, a DC voltage, thermocouple, resistance temperature detector, or contact signal can be set to each channel. The data saved on a CF card/SD card or the data transferred via networks can be converted to Lotus 1-2-3, Excel, or ASCII format file, facilitating processing on a PC. Not only this, the Viewer software allows a PC to display waveforms on its screen and to print out waveforms.
FX1002-4-3-H/C2 Measurement Input
Model:FX1002
No. of Measurement Channels:2
Scan Interval:125 ms, 250 ms
A/D converter integration time:AUTO*1, 50 Hz,60 Hz
FX1002-4-3-H/C2 Displayed Information
Display groups: Assign channels to groups on the trend display, digital display, and bar graph display and display.
Number of groups: 10
Number of channels that can be assigned to each group:Up to six
Channel: Select from 24 colors
Background:White or black (excludes the Overview display. See the item on the Historical trend display for information on that display.)
Trend display:Waveform line width select from 1, 2, and 3 dots
Trend intervals:15 s, 30 s, 1 min, 2 min, 5 min,10 min, 15 min, 20 min, 30 min, 1 h, 2h, 4 h, or 10 h/div for the FX1002 and FX1004.30 s, 1 min, 2 min, 5 min, 10 min,15 min, 20 min, 30 min, 1 h, 2 h, 4 h,or 10 h/div for the FX1006, FX1008,
FX1010, and FX1012.
FX1002-4-3-H/C2 Event Data
Target : Measurement/computation channel.
Sampling interval :Determined by the sample rate.125 ms, 250 ms, 500 ms, (FX1002 and FX1004 only)1 s, 2 s, 5 s, 10 s, 30 s, 1 min, 2 min,5 min, or 10 min.The sampling interval cannot be shorter than the scan interval.
Number of computation channels:FX1002 and FX1004: 12 channels (101 to 112)FX1006, FX1008, FX1010, and FX1012: 24 channels (101 to 124)
Input terminal:All the RTD input terminals (A, B, and b)are isolated on each channel.Applies to the FX1006, FX1008, FX1010,and FX1012
Note: On the FX1002 and FX1004 standard models, theA, B, and b terminals are already isolated on each channel.
FX1002-4-3-H/C2 DATASHEET DOWNLOAD
