YOKOGAWA SCP451-11 PROCESSOR MOUDLE CPU
YOKOGAWA SCP451-11 PROCESSOR MOUDLE CPU 100% Brand New. 365 days warranty.
item no.:
SNB10D-223/CU2Nlead time:
2-3 work daysproduct orgin:
Japanshipping port:
Xiamen Chinapayment:
T/Tmarket price:
$999price range:
1-999/1$color:
Depends on the materialSNB10D-223 GENERAL
This GS describes the hardware specifications of the safety node unit (SNB10D). The safety node unit is connected to the safety control unit. The safety node unit has an interface function to transmit analog input signals and contact signals from the field to the safety control unit via an ESB bus. It also has a function to supply power to I/O modules. The safety node unit is mounted with power supply modules, ESB bus interface modules, optical ESB bus repeater modules, and I/O modules. For details on the I/O modules, refer to the general specifications (GS 32Q06K30-31E and GS 32Q06K40- 31E).
-Up to 13 safety node units can be connected to S2SC70S/S2SC70D/SSC60S/SSC60D safety control unit using SEC402 ESB bus coupler module.
-Up to 9 safety node units can be connected to safety control unit using SEC401 ESB bus coupler module.
The power supply voltage is specified in the suffix codes.
Voltage: 100 to 120 V AC and 50/60 Hz frequency
Voltage: 220 to 240 V AC and 50/60 Hz frequency
Voltage: 24 V DC
100 to 120 V AC specification: 200 VA
220 to 240 V AC specification: 230 VA
24 V DC specification: 5.5 A
Approx. 5.9 kg
Rack mounting: Rack mount with four M5 screws Insulation bushes (accessories) are used.
SNB10D Safety Node Unit(Rack Mountable Type)
Suffix Codes
–2 Dual-redundant power supply with software license for node expansion (R3) (*1)
–4 Dual-redundant power supply (R4.01 or later)
1 100 to 120 V AC power supply
2 220 to 240 V AC power supply
4 24 V DC power supply
5 ISA Standard G3 and temperature (-20 to 70 ˚C) with no explosion protection
E ISA Standard G3 and temperature (-20 to 70 ˚C) with explosion protection
Option Codes
/CU2N Connector Unit for ESB Bus [Part number: S9342FA]
/CU2T Connector Unit with Terminator for ESB Bus [Part number: S9343FA]
/ATDOC Explosion Protection Manual
