BOARD PRINTED CIRCUIT VMD-TWW103-M1 SIGNAL CONDITIONER TWW 103M1
SIGNAL CONDITIONER
item no.:
CP103 143-103-000-93lead time:
2-3daysproduct orgin:
Switzerlandpayment:
T/TCondition:
newCP103 143-103-000-931 FEATURES
From the Vibro-Meter® product line
Extreme temperature capability −196 to +700°C
High-pressure capability up to 250 bar
For use in gas turbines
Operational in primary circuit of PWR, APWR,BWR, ABWR, FBR and HTGR
Proven reliability
Meets NRC guide 1.20, IEEE 323-1974
Certified for use in potentially explosive atmospheres
Internal case insulation
VC2 type crystal element
Frequency response: 2 to 10000Hz
Input power requirements : None
Signal transmission : 2-pole system insulated from casing, charge output
Signal processing : Charge converter
Sensitivity (at 2 Hz) : 232 pC/bar (16 pC/psi) ±5% typical
Dynamic measuring range (random) : 0.00004 to 20 bar nominal
Overload capacity (spikes) : Up to 250 bar
Linearity : ±1% over dynamic measuring range
Acceleration sensitivity : ≤0.05 pC/g (≤0.000 21 bar/g)
Resonant frequency : >50 kHz
Frequency response : 2 to 10000 Hz ±5% (the lower cut-off frequency is determined by the electronics used)
Continuous operation : −54 to +650°C (−65 to +1202°F)
Extreme operation : −196 to +700°C (−321 to +1292°F)
Gamma flux : 1011 erg/g no effect
Neutron flux : 1018 n/cm2 no effect
CP103 143-103-000-931 DATASHEET DOWNLOAD
