newIQS450 204-450-000-002-A2-B23-H05-I1 KEY FEATURES AND BENEFITS
From the vibro-meter® product line
Non-contact measurement system based on eddy-current principle
Ex certified versions for use in hazardous areas(potentially explosive atmospheres)
TQ401 conforms to API 670 recommendations
5 and 10 m systems
Temperature-compensated design
Voltage or current output with protection against short circuits
Frequency response: DC to 20 kHz (−3 dB)
Measurement range: 2 mm
Temperature range: −40 to +180 °C
IQS450 204-450-000-002-A2-B23-H05-I1 DESCRIPTION
The TQ401, EA401 and IQS450 form a proximity measurement system from Meggitt’s vibro-meter®
product line. This proximity measurement system allows contactless measurement of the relative
displacement of moving machine elements.
TQ4xx-based proximity measurement systems are particularly suitable for measuring the relative
vibration and axial position of rotating machine
shafts, such as those found in steam, gas and hydraulic turbines, as well as in alternators, turbocompressors and pumps.
Voltage at min. GAP : −1.6 V
Voltage at max. GAP : −17.6 V
Dynamic range : 16 V
Output impedance : 500 Ω
Short-circuit current : 45 mA
Current at min. GAP : −15.5 mA
Current at max. GAP : −20.5 mA
Dynamic range : 5 mA
Output capacitance : 1 nF
Output inductance : 100 µH
Voltage : −20 to −32 V*
Current : −13 mA ±1 mA (−25 mA max.)
Voltage : −20 to −32 V*
Current : −15.5 to −20.5 mA
Input : Self-locking miniature coaxial connector (female).Note: When connecting, this should be hand-tightened, until locked.
Output and power supply : Three screw terminals – wire section 2.5 mm2 max.
Standard version : 140 g approx.
Ex version : 220 g approx.
