GE Fanuc IC698CPE010 Processor Module CPU
GE Fanuc IC698CPE010 Processor Module CPU 100% Brand New. 365 days warranty.
item no.:
GE IS220PSCAH1Blead time:
1-2 daysproduct orgin:
The USAshipping port:
Xiamenpayment:
T/TCondition:
NEWIS220PSCAH1B Functional Description
The Serial Communication Input/Output (PSCA) pack provides the electrical interface between one or two I/O Ethernet networks and a serial communications terminal board.
The pack contains a processor board common to all Mark* VIe distributed I/O packs and a serial communications board.
The communications board contains six serial transceiver channels, each of which can be individually configured to comply with RS-232, RS-422, or RS-485 half duplex standards.
Input to the pack is through dual RJ45 Ethernet connectors and a three-pin power input.
Output is through a DC-62 pin connector that connects directly with the associated terminal board connector.
One of the Ethernet ports can be used to support Ethernet Modbus communication on Simplex Networks. Visual diagnostics are provided through indicator LEDs, and local diagnostic serial communications are possible through an infrared port.
To install the PSCA pack
1 Securely mount the desired terminal board.
2 Directly plug one PSCA pack into the terminal board connector.
3 Mechanically secure the packs using the threaded inserts adjacent to the Ethernet ports. The inserts connect with a mounting bracket specific to the terminal board type. The bracket location should be adjusted such that there is no right angle force applied to the DC-62 pin connector between the pack and the terminal board. The adjustment should only be required once in the life of the product.
4 Plug in one or two Ethernet cables depending on the system configuration. The pack operates over either port. If dual connections are used, standard practice is to hook ENET1 to the network associated with the R controller, however, the PSCA is not sensitive to Ethernet connections and will negotiate proper operation over either port.
5 Apply power to the pack by plugging in the connector on the side of the pack. It is not necessary to insert this connector with the power removed from the cable as the I/O pack has inherent soft-start capability that controls current inrush on power application.
6 Configure the I/O pack as necessary.
The processor board in the pack is common to all Mark VIe Ethernet I/O packs.
It contains the following:
• High-speed processor with RAM and flash memory
• Two fully independent 10/100 Ethernet ports with connectors
• Hardware watchdog timer and reset circuit
• Internal I/O pack temperature sensor
• Infrared serial communications port
• Status-indication LEDs
• Electronic ID and the ability to read IDs on other boards
• Substantial programmable logic supporting the acquisition board
• Input power connector with soft start/current limiter
• Local power supplies, including sequencing and monitoring
The following I/O pack and terminal board combinations are approved for use in hazardous locations
Serial communication I/O pack IS220PSCAH1A or IS220PSCAH1B with accessory terminal board IS200SSCAH1A or IS200SSCAH2A
Coated serial communication I/O pack IS221PSCAH1B with accessory terminal board IS201SSCAH1A or IS201SSCAH2A
Serial communication I/O pack IS42yPSCAH1B with accessory terminal board IS40ySSCAH1A or IS40ySSCAH2A (where y = 0 or 1)
