GE Fanuc IC698CPE010 Processor Module CPU
GE Fanuc IC698CPE010 Processor Module CPU 100% Brand New. 365 days warranty.
item no.:
IS420UCSCS2Alead time:
5-7 DAYSproduct orgin:
USAshipping port:
XIAMEN, CHINApayment:
T/Tcolor:
DEPENDING ON THE MATERIALPart Number: IS420UCSCS2A
Manufacturer: General Electric
Series: Mark VIeS
Microprocessor: Dual core, 1.6 GHz AMD G-Serie
Memory Storage: 128 GB Solid State Drive
Dimensions: 168 x 150 x 55 mm
Weight: 1.4kg
Country of Manufacturer: USA
Controller Replacement Part Number: IS420UCSCS2A
Features
The Mark VIeS Safety controller, IS420UCSCS2A, is a dual core controller that runs the Mark VIeS Safety control applications used for functional safety loops to achieve SIL 2 and SIL 3 capabilities. The Mark VIeS Safety product is used by operators that are knowledgeable in safety-instrumented system (SIS) applications to reduce risk in safety functions.
The UCSCS2A controller can be configured for Simplex, Dual, and TMR redundancy. The non-safety Mark VIe controller, IS420UCSCH1B, can be interfaced with the Safety control system (through EGD protocol on UDH Ethernet port) as a controller for non-SIF loops or as a simple communication gateway to provide data with OPC ® UA Server or Modbus ® Master feedback signals, if needed by the application. The following table provides the specifications for the UCSC controllers.
For more
information on the UCSC controller, refer to “UCSC Controllers” in the document Mark
VIeS Functional Safety Systems for General Market Volume II: System Guide for Generalpurpose Applications (GEH-6855_Vol_II).
3 IONet ports (R/S/T) for I/O module communications (simplex,
dual, and TMR supported); ENET 1 - EGD/UDHcommunications
to ToolboxST PC, HMIs, UCSCH1B Gateway controller, and GE
PACSystems products; Modbus TCP Slave, Read-only; Supports
Black Channel communication between other Mark VIeS Safety
controllers
• Function Block Diagram (FBD)
• Relay Ladder Diagram (RLD)
• Cause and Effect Matrix
Refer to ToolboxST User Guide for Mark Controls Platform
Base-mounted. For mounting details and spacing requirements details, refer to the section “UCSC Controllers” in the documentMark
VIeS Functional Safety Systems for General Market Volume II: System Guide for General-purpose Applications.
The front faceplate of the controller module features a set of user-friendly connectivity options. It includes six female jack connectors, allowing for easy and secure cable connections. Additionally, a USB port is provided for convenient data exchange and configuration. The faceplate also incorporates a series of LED indicators that provide valuable information about the module's status and operation.
| IS200ACLEH1ABA | IS200STAIH2ACB | IS200VAICH1C | IS220PAICH2A | IS220PAICH1B |
| IS200BICIH1ACA | IS200STAOH2AAA | IS200VAICH1D | IS220PAOCH1 | IS220PTURH1A |
| IS200BICIH1ADB | IS200STCIH6ADD | IS200VAICH1DAA | IS220PAOCH1B | IS220PAOCH1A |
| IS200BICLH1AFD | IS200TAMBH1ACB | IS200VCMIH2BCC | IS220PDIAH1B | IS220PDIIH1A |
| IS200BICLH1AFF | IS200TBAIH1CCC | IS200VCRCH1B | IS220PDIOH1A | IS220PDIAH1A |
| IS200BICLH1BAA | IS200TBAIH1CED | IS200VCRCH1BBB | IS220PDIOH1B | IS220PDIOH1A |
| IS200BICLH1BBA | IS200TBCIH1B | IS200VRTDH1DAB | IS220PDOAH1A | IS220PAICH2A |
| IS200BPVCG1BR1 | IS200TBCIH1BBC | IS200VSVOH1BDC | IS220PDOAH1B | IS220PDOAH1A |
| IS200DSPXH1DBD | IS200TBTCH1CBB | IS200VTCCH1C | IS220PPDAH1B | IS230PCAAH1A |
| IS200EACFG3BAA | IS200TDBTH2ACC | IS200VTCCH1CBB | IS220PPRFH1A | IS230SNAOH2A |
| IS200EBKPG1C | IS200TDBTH6ABC | IS200VTURH1BAA | IS220PPROH1A | IS230SNRLH2A |
| IS200EDCFG1BAA | IS200TDBTH6ACD | IS200VTURH1BAB | IS220PRTDH1A | IS230TNPAH2A |
| IS200EDEXG1B | IS200TPROH1BBB | IS200VTURH2B | IS220PSCAH1A | IS230TPROH3C |
| IS200EHPAG1D | IS200TPROH1CAA | IS200VVIBH1CAB | IS220PTCCH1A | IS215VCMIH2BB |
| IS200EPBPG1A | IS200TREGH1BDB | IS2020RKPSG2A | IS220PTURH1A | IS215VCMIH2BC |
| IS200EPCTG1AAA | IS200TRLYH1BED | IS2020RKPSG3A | IS220PTURH1B | IS200TTURH1B |
| IS200EPSMG2AEC | IS200TRLYH1BFD | IS210BAPAH1A | IS220PVIBH1A | IS200TTURH1BCC |
| IS200ERBPG1ACA | IS200TRLYH1BGF | IS215UCCCM04A | IS220UCSAH1A | IS200EXHSG3AEC |
| IS200ERDDH1ABA | IS200TRLYH1BGG | IS215UCVDH7A | IS220YAICS1A | IS200JPDEG1A |
| IS200ERIOH1AAA | IS200TRPAH2AHE | IS215UCVEH2A | IS220YDOAS1A | IS215VAMBH1ADX |
| IS200EROCH1ABB | IS200TRPGH1BCC | IS215UCVEH2AE | IS200ESELH2AAA | IS200TSVOH1BBB |
| IS200ERSCG1AAA | IS200TRTDH1CCC | IS215VAMBH1A | IS420UCSBH3A | IS420UCSCH1A |
| IS400JPGPA1ACD | IS400TCASH1AGD | IS415UCVHH1A | IS420UCSCS2A | IS420UCSCH1B |
| IS200WNPSH1A | IS400JPDMG1A | IS200EAUXH1A | IS420UCSCH1B | IS420UCSBH3A |
