AAI543-S50 Specifications

Model: AAI543-S50
Number of output channels :16, isolated, standard switch-over response in redundant configuration
Output signal : 4 to 20 mA
Withstanding voltage : Between output and system: 1500 V AC, for 1 minute
Allowable load resistance : 0 to 750 Ω
Circuit-open detection : Less than 0.65 mA
Accuracy :±48 µA
Data update period :10 ms
Drift due to ambient temperature change : ±16 µA/10 ˚C
Maximum current consumption: 230 mA (5 V DC), 540 mA (24 V DC)
Weight : 0.4 kg
External communication: Pressure clamp terminal, MIL connector cable, dedicated cable
HART communication: Available

AAI543-S50 MODEL AND SUFFIX CODES

Model-AAI543-Analog Output Module (4 to 20 mA, 16-channel, Isolated)
Suffix Codes -S- Standard type
Suffix Codes -H-With digital communication (HART protocol)
Suffix Codes-5-Standard switch-over response in redundant configuration with no explosion protection
Suffix Codes-6-Fast switch-over response in redundant configuration with no explosion protection
Suffix Codes-E-Standard switch-over response in redundant configuration with explosion protection
Suffix Codes-F-Fast switch-over response in redundant configuration with explosion protection
Suffix Codes-0-Basic type
Suffix Codes-1-With ISA Standard G3 option
Suffix Codes-3-With ISA Standard G3 option and temperature (-20 to 70 °C) option
Option Codes /K4A00 -With KS Cable Interface Adapter (For connecting AEA4D Terminal Board)
Option Codes /A4S00 -With Pressure Clamp Terminal Block
Option Codes /A4S10 -With Pressure Clamp Terminal Block (surge absorber)
Option Codes /A4D00-With Dual Pressure Clamp Terminal Block
Option Codes/A4D10 -With Dual Pressure Clamp Terminal Block (surge absorber)
Option Codes/CCC01 -With Connector Cover for MIL Cable
