Yokogawa MW100 Data Acquisition Unit model

Yokogawa Data Acquisition Unit

item no.:
MW100
lead time:
2-3days
product orgin:
JAPAN
payment:
T/T
Condition:
new

product details

MW100 Description

Model: MW100
Description: Main module (with MW100 Viewer Software)
Language-E-English (with English user’s manual)
Power supply voltage-1-100 VAC–240 VAC
Power supply voltage-2-12 VDC–28 VDC, with AC adapter
Power supply voltage-3-12 VDC–28 VDC, without AC adapter
Power supply inlet and power supply cord-D-AC power: 3-pin power inlet with UL/CSA cable
DC power: Screw terminal, UL/CSA cable for AC adapter
Power supply inlet and power supply cord-F-AC power: 3-pin power inlet with VDE cable
DC power: Screw terminal, VDE cable for AC adapter
Power supply inlet and power supply cord-R-AC power: 3-pin power inlet with SAA cable
DC power: Screw terminal, SAA cable for AC adapter
Power supply inlet and power supply cord-Q-AC power: 3-pin power inlet with BS cable
DC power: Screw terminal, BS cable for AC adapter
Power supply inlet and power supply cord-H-AC power: 3-pin power inlet with GB (CCC) cable
DC power: Screw terminal, GB (CCC) cable for AC adapter
Power supply inlet and power supply cord-W-Screw terminal, power supply cord not included
Options/C2-RS-232 communication interface
Options/C3-RS-422A/485 communication interface
Options/M1-MATH function

MW100 Functions

The MW100 is equipped with built-in trigger functions. Data recording can be started based on alarm values, time, external contact input, or other parameters. Once recording is started, it can be set to progress continuously or according to a specified data length. When specifying a data length, a pre-trigger can also be set. The MW100 also provides a data thinning function.
Portions of measured data can be omitted at regular intervals during measurement (minimum of four seconds) before data is recorded. Using the trigger and data thinning functions together provides "coarse" recording of general data and "fine" recording of abnormal data.

MW100 Specifications

Main functions: Control of the power supply and I/O modules, communications with the PC, and storage of data on the CF card.

Measurement interval: 10/50/100/200/500 ms, or 1/2/5/10/20/30/60 sec

Note : the configurable measurement intervals differ depending on the modules.Also, the following limitations apply to the measurement interval and number of measurement channels.

Synchronization between modules: Synchronized within the same measurement interval (within the same unit)

Synchronization between channels: Synchronized between channels in the same module for the MX110-UNVH04 and the MX115-Dxx-H10. Channels within the MX110-UNV-M10,MX110-V4R-M06, and M112 input modules are asynchronous due to the scanner type.

Filter function: First-order lag filter can be set on each channel.

Operation after failure recovery: After recovery from a power failure, the operation before the failure is continued.
