YOKOGAWA UP150-VN/V24 Program Temperature Controller Model

YOKOGAWA Program Temperature Controller

item no.:
UP150-VN/V24
lead time:
2-3days
product orgin:
JAPAN
payment:
T/T
Condition:
new

contact now

product details

UP150 SPECIFICATIONS

The UP150 program temperature controller has one program pattern consisting of 16 segments, and it can easily be set and operated.

The two event outputs are provided as standard,and the external contact input, communication and retransmission output as options.
The universal input selectable an input type among TC, RTD and Voltage, and the three types of outputs are also provided.
The front panel has a splash-proof and dust-proof design (IP65), which enables the use in the dusty environment.

UP150-VN/V24 MODEL AND SUFFIX CODES

UP150 Program Temperature Controller
Control output-R-Relay output (time-proportional PID or on/off control)
Control output-V-Voltage pulse output (time-proportional PID)
Control output-A-4 to 20 mA output (continuous PID)
Fixed code-N-Always N
Option/EX/RUN/RESET switching, and HOLD program/cancel HOLD program switching by external contacts (Note1)
Option/RET/PV retransmission output in 4 to 20 mA
Option/RS/Communication function(MODBUS, PC-Link, Ladder) (Note1) (Note2)
Option/V24/Power Supply 24 V DC / 24 V AC

UP150-VN/V24 DISPLAY AND OPERATION FUNCTIONS

SEG lamp (green)

Lit when the value of segment no. or remaning segment time is displayed on SP display.

EV1, EV2 lamps (red)

EV1 : Lit when event 1 (PV event 1 or Time event 1) is activated.
EV2 : Lit when event 2 (PV evnet 2 or Time evnet 2) is activated.

RUN lamp (orange)

Lit while the operation mode is “RUN”.
Flashing while the operation mode is “WAIT”.

HLD (hold) lamp (green)

Lit while the operation mode is “HOLD”.

SET/ENT key(data registering key)

Switches the operating displays.
Registers the data value changed using the data change keys.
Switches between parameter setting displays sequentially.
Pressing the key for 3 seconds or longer in the operating display retrieves the operating parameter setting display.
Pressing the key for 3 seconds or longer in operating, setup or program parameter setting display transfers back to operating display.

PV display (red)

Indicates PV (measured value) and character information such as parameter codes and error codes. Indicates PV and “AT” alternately during Auto-tuning.

SP display (green)

Indicates SP (target setpoint), segment no.,remaining segment time and parameter setpoints.

Data change key (or Reset key)

Pressing this key for more than 1 second (in operating display) stops (resets) the program operation.
Changes the program setpoints(SP) and the parameter setpoints.
Pressing this key increases the parameter setpoint.Holding down the key will gradually increase the speed of changes

Data change key (or Run key)

Pressing this key for more than 1 second (in operating display) starts (runs) the program operation.
Changes the program setpoins(SP) and the parameter setpoints.
Pressing this key decreases the parameter setpoint.Holding down the key will gradually decrease the speed of changes.
