YOKOGAWA UT150-VV/AL Temperature Controller

UT150 Model and Suffix Codes

• Type

UT150
48x48x100mm
4-digit display
Number of SP: 2

• Standard Type Model

UT150-RN Without alarm/Without other options/Relay output
UT150-VN Without alarm/Without other options/Voltage pulse output
UT150-AN Without alarm/Without other options/Current output
UT150-RN/AL With 2 alarms/Without other options/Relay output
UT150-VN/AL With 2 alarms/Without other options/Voltage pulse output
UT150-AN/AL With 2 alarms/Without other options/Current output
UT150-RN/AL/RET With 2 alarms/With retransmission output/Relay output
UT150-VN/AL/RET With 2 alarms/With retransmission output/Voltage pulse output
UT150-AN/AL/RET With 2 alarms/With retransmission output/Current output
UT150-RN/AL/EX With 2 alarms/With external contact input/Relay output
UT150-VN/AL/EX With 2 alarms/With external contact input/Voltage pulse output
UT150-AN/AL/EX With 2 alarms/With external contact input/Current output
UT150-RN/AL/RS With 2 alarms/With communication/Relay output
UT150-VN/AL/RS With 2 alarms/With communication/Voltage pulse output
UT150-AN/AL/RS With 2 alarms/With communication/Current output
UT150-RN/AL/RET/EX With 2 alarms/With retransmission output/external contact input/Relay output
UT150-VN/AL/RS With 2 alarms/With retransmission output/external contact input/Voltage pulse output
UT150-AN/AL/RS With 2 alarms/With retransmission output/external contact input/Current output

• UT150 Standard Type

UT150 Temperature controller (48 x 48 x 100mm)
Control output-R-Relay output (time-proportional PID or on/off control)
Control output-V-Voltage pulse output (time-proportional PID control)
Control output-A-4 to 20mA output ( current PID) (Note1)
Fixed -N-Fixed
Option/AL-Alarm outputs (2 points) (Note2)
Option/HBA-Heater disconnection alarm (includes the function of " /AL" option) (Notes 2 and 3)
Option/EX/SP1/SP2 switching, starting of timer, and RUN/STOP switching byexternal contacts (Notes 4 and 5)
Option/RET/PV retransmission output in 4 to 20mA (Note 3)
Option/RS/Communication function (Notes 4 and 6)
Option/V24/Power Supply 24V DC / 24VAC

• UT150 Heating/Cooling Type

UT150 Temperature controller (48 x 48 x 100mm)
Control output for heating-R-Relay output (time-proportional PID or on/off control)
Control output for heating-V-Voltage pulse output (time-proportional PID control)
Control output for heating-A-4 to 20mA output ( current PID) (Note1)
Control output for cooling-R-Relay output (time-proportional PID or on/off control)
Control output for cooling-V-Voltage pulse output (time-proportional PID control)
Control output for cooling-A-4 to 20mA output ( current PID) (Note1)
Option/AL-Alarm outputs (2 points) (Note2)
Option/HBA-Heater disconnection alarm (includes the function of " /AL" option) ((Notes 2 and 3)
Option/EX-SP1/SP2 switching, starting of timer, and RUN/STOP switching byexternal contacts (Notes 3 and 4)
Option/RS-PV retransmission output in 4 to 20mA
Option/V24-Power Supply 24V DC / 24VAC

• Terminal Cover

L4000FB:Terminal cover for models UT130 and UT150 (1 set)

• Mounting Bracket

L4000FA:Mounting bracket for models UT130 and UT150 (1 piece)

• SP2 lamp (green)

Lit when SP2 is being used for control operation.

• Alarm 1 (AL1), Alarm 2 (AL2) lamps (red)

AL1: Lit when the alarm 1 is activated.
AL2: Lit when the alarm 2 is activated.

• Output (OUT) display lamps

Lit while control output is being output.
Flashes according to the control output value during timeproportional output or current output. (Flashes slowly when current control output value is small; flashes fast when it is large.)

•  The left lamp is lit in orange during control output of standard type.

 In heating/cooling control, the left lamp lights up in orange when
 the heating-side output is active; while the right lamp lights up in
 green when the cooling-side output is active.

• SET / ENT key (data registering key)

 Registers the data value changed using the data change keys.
 Switches between operating displays or parameter setting displays sequentially.
 Pressing the key for 3 seconds or more in the operating display retrieves the operating parameter setting   display. You can transfer to the setup parameter setting display form the operating parameter setting display.
 Pressing the key for 3 seconds or more in either an operating or setup parameter setting display transfers back to operating display.

• PV display (red)

Indicates PV (measured value) and character information
such as parameter codes and error codes.

• SP display (green)

Indicates SP (target setpoint) and parameter values.

This chapter describes an operating procedure using temperature controllers UT130
and UT150 of standard type with the alarm option as an example. Regarding the
operating procedure for the heating/cooling type controller or for the controller with the
options other than the alarm, confirm whether the some parameters appear or not
referring to the parameter flowchart in “3. NAMES AND FUNCTIONS OF EACH PART /
PARAMETERS.” The operating procedure for UT152/UT155 is the same as that for
UT150.

UT150-VV/AL DATASHEET DOWNLOAD
